ROGER TECHNOLOGY TW90 Brushless Sliding Gate Motor | 24V | Up to 600kg

Sliding Gate Operator

Code: TW90*

From £668.09 £556.74 Ex Vat Ex Vat Inc Vat Inc Vat
|
|
(%)

Item in Stock | Usually dispatched within 24 hours

Product Details
Delivery & Returns
Payment & Security
Reviews

Product Overview

The TW90 Brushless Sliding Gate Motor is designed for super intensive use, supporting sliding gates up to 600kg. This electromechanical motor operates on 24V and features a high-speed brushless design. It comes equipped with a sensored digital magnetic encoder at 4096 PPR and is available with either separate or built-in control panels. The TW90 motor is available in various configurations, including high-speed and reversible options, ensuring flexibility for different installation needs.

Key Features

24V power supply
High speed option available
Irreversible or reversible options
Separate or built-in control panel options
Supports sliding gates up to 800kg

Motor Options

TW90/620/HS - Up to 600kg | High Speed | 24V | Separate control panel
TW90/800 - Up to 800kg | 24V | Built-in control panel
TW90/800/R - Up to 800kg | Reversible | 24V | Built-in control panel
TW90/820 - Up to 800kg | 24V | Separate control panel
TW90/820/R - Up to 800kg | Reversible | 24V | Separate control panel

Reversible Motors

Roger Technology reversible motors lock in the open and closed positions while the power is on but unlock as the power goes off. This feature is useful for emergency free exits during power cuts. Other brands' reversible motors are always unlocked and require an electric lock in the open and closed positions.

Specifications

	TW90/620/HS	TW90/800	TW90/800/R	TW90/820	TW90/820/R
Max Gate Weight (kg)	600	800	800	800	800
Power Line Supply	230V AC - 50Hz	230V AC - 50Hz	230V AC - 50Hz	230V AC - 50Hz	230V AC - 50Hz
Motor Power Supply	24V	24V	24V	24V	24V
Power Rating (W)	180	180	130	180	180
Frequency of Use	Intensive use	Intensive use	Intensive use	Intensive use	Intensive use
Thrust (N)	250	385	270	385	270
Operating Temperature (°C)	-20 to +55	-20 to +55	-20 to +55	-20 to +55	-20 to +55
Protection Level	IP44	IP44	IP44	IP44	IP44
Reductor Type	Irreversible	Irreversible	Reversible	Irreversible	Reversible
Manoeuvre Speed (m/min)	25 (0.42)	12.3 (0.2)	18 (0.3)	12.3 (0.2)	18 (0.3)
Limit Switch	Without limit switches - optional	Without limit switches - optional	Without limit switches - optional	Without limit switches - optional	Without limit switches - optional
Onboard Control Unit	B70/1T	B70/1T	B70/1T	B70/1T	B70/1T
Encoder	Digital magnetic encoder SENSORED, 4096 PPR	Digital magnetic encoder SENSORED, 4096 PPR	Digital magnetic encoder SENSORED, 4096 PPR	Digital magnetic encoder SENSORED, 4096 PPR	Digital magnetic encoder SENSORED, 4096 PPR
Batteries Recovery	-	Optional 2 internal battery 12V 1.2AH	Optional 2 internal battery 12V 1.2AH	-	-
Type Exit Gear	Z15/mod 4	Z15/mod 4	Z15/mod 4	Z15/mod 4	Z15/mod 4
Operating Cycles per Day	150000	150000	150000	150000	150000
Maximum Dimension Product (L x W x H in mm)	166 x 134.4 x 214.5	132 x 138.5 x 470	132 x 138.5 x 470	166 x 134.4 x 214.5	166 x 134.4 x 214.5
